MIL-PRF-39012/19H
TABLE I. Dash numbers, Cross-reference, and dimensions Continued.
Inches (millimeters)
PIN 1/
Applicable cable 2/
Dimensions
maximum #
M39012/19-
M17/
Category D Field replaceable Defined piece part 3/ 8/ 13/ 14/
X501
Cable group IV
54-RG122 6/
X502
Cable group V
A
1.468 (37.31)
95-RG180 5/ 6/ 7/
X503
Cable group VIB
60-RG142 5/
128-RG400 6/
X504
Cable group VIA
111-RG303 5/ 6/
1/ For cross-reference of PIN to superseded PIN or designation, see table IV.
2/ The latest version of each cable shall be applicable.
3/ These connectors have captivated center contacts.
4/ The superseded PIN is NOT acceptable for Government use.
5/ Cable to be used for the +200°C temperature cycling tests. This cable may be used for tests with the
approval of the Qualifying Activity.
6/ Cable to be used when performing test requiring cable except as in 5/ and 7/.
7/ These are not 50-ohm cables; therefore, when attached to the specified connectors, VSWR, RF
leakage and insertion loss are not applicable.
8/ These connectors are assembled using the applicable crimp tool, to the specified cables stripped as
shown on figure 4.
9/ M22520/5-19 closure B or M22520/5-05 closure A.
M22520/5-11 closure A.
M22520/5-57 closure A.
