MIL-PRF-39012/2H
Crimp die
Ferrule
or
A
B
Basic crimp
Dash
number
C ± .015
positioner
± .003
± .003
Tool 2/
1/
number
M22520/5
X501
2-50
.492
.438
.600
25
X511
Closure A
X502
or 61
2-51
.492
.418
.600
X512
M22520/5-01
X503
5, 11, 57
2-52
.250
.220
.500
X513
Closure A
or 19
X504
2-53
.245
.206
.500
Closure B
X514
1/ Ferrule numbers are for identification only.
2/ Class 2 tool may be used by OEM (see MIL-DTL-22520).
FIGURE 3. Contact and ferrule dimensions for category D only Continued.
Inches
mm
.177
4.50
.197
5.00
.396
10.06
.416
10.57
.490
12.45
.510
12.95
.687
17.45
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
FIGURE 4. Cable stripping dimensions for field replaceable connectors.
10
