MIL-PRF-39012/2H
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.001
0.03
.043
1.09
.207
5.26
.438
11.13
.002
0.05
.098
2.49
.220
5.59
.476
12.09
.003
0.08
.104
2.64
.234
5.94
.492
12.50
.005
0.13
.120
3.05
.245
6.22
.500
12.70
.015
0.38
.156
3.96
.250
6.35
.600
15.24
.031
0.79
.187
4.75
.292
7.42
.036
0.91
.206
5.23
.418
10.62
Basic crimp
Crimp
Crimp die
Color band
Color band
Contact no.
Dimension
tool 2/
tensile minimum,
Dash no.
or positioner
Ο
1/
A
M22520/1 3/
pounds (N)
M22520/1
X501
60
X502
.098 ± .002
2-10
-01
-13
(266.90)
Red
Brown
X511
X512
X503
.043
20
X504
2-11
+ .001
-01
-13
(88.96)
Blue
Brown
X513
- .002
X514
1/ Contact numbers are for identification only.
2/ Class 2 tool may be used by OEM (see MIL-DTL-22520).
3/ Optional tool: M22520/5-01 with M22520/5-25 closure B die.
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Contact material shall be copper beryllium. Connectors supplied with phosphor bronze
contacts are acceptable for Government use until existing stock is purged. This
elimination of the contact material option shall take effect 1 year from the date of this
specification.
4. Crimp tensile test shall be in accordance with SAE-AS39029.
5. Copyright notice: All information disclosed in this specification sheet which is or may be
copyrighted is reproduced herein with the express permission of the copyright owner.
6. Maximum break of .003 inch (0.08 mm).
7. Color bands shall be positioned such that no coloring material enters the inspection hole.
FIGURE 3. Contact and ferrule dimensions for category D only.
9
