MIL-PRF-39012/26H
TABLE III. Category B nonfield replaceable (special tools may be required).
.
Not for Air Force, Army, or Navy use. For OEM use only.
Applicable
Inches
Dash number
cable M17/
Dimensions
(millimeters)
1/ 2/ 3/
4/
maximum 5/
M39012/26B0005
28-RG058*
M39012/26B0006
60-RG142*@
128-RG400
M39012/26B0007
29-RG59*^
30-RG062 ^
97-RG210 ^
M39012/26B0008
54-RG122*
A
1.500 (38.10)
M39012/26B0009
90-RG71*^
M39012/26B0015
111-RG303*@
M39012/26B0019
110-RG302 *@ ^
84-RG223 @
M39012/26B0020
113-RG316* @
1/ For cross-reference of dash number to superseded PIN or type designation, see table IV.
2/ For maintenance replacements for category B, see table V.
3/ Inactive for new design.
4/ The latest version of each cable shall be applicable.
5/ Dimensions are in inches. Metric equivalents are given for information only.
* Cable to be used when performing tests requiring cable except as in notes @ and ^.
@ Cable to be used for the +200°C temperature cycling tests. This cable can be used for tests with
the approval of the Qualifying Activity.
^ These are not 50 ohm cables; therefore, when attached to the specified connectors, VSWR, RF
leakage, and Insertion loss are not applicable.
13
