MIL-PRF-39012/26H
TABLE I. Dash numbers, cross reference, and dimensions Continued.
PIN 1/
Applicable cable 2/
Inches (millimeters)
Dimensions
M39012/26-
M17/
maximum #
Category D Field replaceable Defined piece part 3/ 7/ 12/ 13/
X501
Cable group IV 6/
54-RG122 5/
X502
Cable group V 6/
95-RG180 4/ 5/
A
1.187 (30.16)
X503
Cable group VIB 6/
60-RG142 4/
128-RG400 5/
X504
Cable group VIA 6/
111-RG303 4/ 5/
1/
For cross-reference of dash number to superseded PIN or designation, see table IV.
2/
The latest version of each cable shall be applicable.
3/
These connectors have captivated center contacts.
4/
Cable to be used for the +200°C temperature cycling tests. This cable can be used for tests with the
approval of the Qualifying Activity.
5/ Cable to be used when performing test requiring cable except as in 5/ and 7/.
6/ Cables that are not 50-ohm cables in this cable group , when attached to the specified connectors,
VSWR, RF, leakage and insertion loss are not applicable.
7/ These connectors are assembled using the applicable crimp tool, to the specified cables stripped as
shown on figure 4.
8/ M22520/5-19 closure B or M22520/5-05 closure A. M22520/5-11 closure A. M22520/5-57 closure A.
9/ M22520/5-19 closure A or M22520/5-07 closure A. M22520/5-13 closure A. M22520/5-59 closure A.
10/ M22520/5-41 closure B or M22520/5-05 closure B. M22520/5-09 closure A.
11/ M22520/5-35 closure B or M22520/5-03 closure A.
12/ Complete connector assembly shall consist of a body, center contact, ferrule and assembly
instructions.
13/ Not to be used in Army equipment.
14/ Armored cable.
# Dimensions are in inches. Metric equivalents are given for information only.
X Denotes connector body plating material option. The only plating options allowable are Silver or
Nickel over brass in accordance with MIL-PRF-39012. Only connectors of the same materials shall
be mated to avoid dissimilar metal problems. CAUTION: A NICKEL PLATED BODY IS NOT FOR
USE IN APPLICATIONS WHERE PASSIVE INTERMODULATION GENERATION (PIM) MAY BE A
CONCERN. Silver is the preferred plating.
5
