MIL-PRF-39012/26H
Crimp die
A
B
Basic crimp
Ferrule
Dash number
or positioner
number 1/
tool 2/
± 0.003
± 0.003
M22520/5
05 or 41
Closure B
X501
or
26-50
0.212
0.175
X502
9 Closure A
M22520/5-01
X503
26-51
0.250
0.220
05, 11, 57
Closure A
or
X504
26-52
0.245
0.206
19 Closure B
1/ Contact numbers and ferrule numbers are for identification only.
2/ Class 2 tool may be used by OEM (see MIL-DTL-22520).
FIGURE 3. Contact and ferrule dimensions for category D only.
6
