MIL-PRF-39012/31D
TABLE I. Dash number and overall dimensions.
Inches-millimeters 1/
Maximum
Minimum
Dash no.
Dim
panel
panel
Minimum
Maximum
thickness
thickness
0001
A
1.187 (30.15)
B
.529 (13.44)
.653 (16.59)
.125 (3.18)
.045 (1.14)
0002 2/
A
1.312 (33.32)
B
.654 (16.61)
.778 (19.76)
.250 (6.35)
.045 (1.14)
0003
A
1.312 (33.32)
B
.654 (16.61)
.778 (19.76)
.260 (6.60)
.045 (1.14)
1/ Millimeters are in parentheses.
2/ Not for use in air force equipment.
TABLE II. Group qualification.
Submission and qualification of
Qualifies the following
Group
any of the following connectors
Connectors
I
/31-0001
/31-0001
/31-0002
/31-0002
/32-0001
/32-0001
ENGINEERING DATA:
Nominal impedance: 50 ohms.
Frequency range: 0 to 11,000 MHz.
Voltage rating: 500 volts rms maximum working voltage at sea level; 125 volts rms maximum at 70,000
feet.
Temperature rating: -65° to +165 C.
REQUIREMENTS:
Design and configuration: See figure 1.
Force to engage and disengage:
Longitudinal force: Not applicable.
Torque: 2 inch-pounds maximum.
Coupling proof torque: Not applicable.
Inspection conditions:
Coupling torque: 4 to 6 inch-pounds.
Mating characteristics: See figure 2 for dimensions.
Center contact (female):
Oversize test pin - .057 inch diameter minimum (nonclosed entry contacts only).
Insertion depth - .125 inch minimum.
Number of insertions 1.
Insertion force test: Steel test pin diameter .054 inch minimum.
Test pin finish: 16 microinches.
Insertion force: 2 lbs maximum.
3
