MIL-PRF-39012/5H
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.001
0.03
.043
1.09
.250
6.35
.492
12.50
.002
0.05
.066
1.68
.292
7.42
.500
12.70
.003
0.08
.098
2.49
.350
8.89
.600
15.24
.005
0.13
.104
2.64
.370
9.40
.015
0.38
.156
3.96
.408
10.36
.031
0.79
.220
5.59
.418
10.62
.036
0.91
.234
5.94
.438
11.13
Crimp
Color
Color
Crimp die
Basic crimp
Dimension
Contact no.
Dash
tensile
band
band
tool 2/
or positioner
Minimum,
1/
A
no.
Ο
M22520/1 3/
M22520/1
pounds (N)
60
X501
.098 ± .002
Red
Orange
5-10
-01
-13
(266.90)
X502
20
.043 + .001
X503
Blue
Orange
-01
-13
5-11
(88.96)
-.002
X504
1/ Contact numbers are for identification only.
2/ Class 2 tool may be used by OEM (see MIL-DTL-22520).
3/ Optional tool: M22520/5-01 with M22520/5-25 closure B die.
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Crimp tensile test shall be in accordance with SAE-AS39029.
4. Copyright notice: All information disclosed in these specification sheets which is or may be
copyrighted is reproduced herein with the express permission of the copyright owner.
5. Maximum break of .003 inch (0.08 mm).
6. Color bands shall be positioned such that no coloring material enters the inspection hole.
FIGURE 2. Contact and ferrule dimensions for category D only.
6
