MIL-PRF-39012/5H
Crimp die or
A
B
Basic crimp
Ferrule
C ± .015
Dash number
positioner
± .003
± .003
tool 2/
number 1/
M22520/5-
X501
5-50
.492
.438
.600
25
Closure A
X502
5-51
.492
.418
.600
or 61
M22520/5-01
5, 11, 57
X503
5-52
.250
.220
.500
Closure A
or 19
X504
5-53
.245
.206
.500
Closure B
1/ Ferrule numbers are for identification only.
2/ Class 2 tools may be used by OEM (see MIL-DTL-22520).
FIGURE 2. Contact and ferrule dimensions for category D only Continued.
Inches
mm
.177
4.50
.197
5.00
.396
10.06
.416
10.57
.490
12.45
.510
12.95
.687
17.45
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
FIGURE 3. Cable stripping dimensions for field replaceable connectors.
7
