MIL-PRF-39012/68D
TABLE I. Dash numbers, cross-reference, and dimensions Continued.
Dash No.
# Applicable cable group
Typical mating
Dimensions
Inches 2/
from MIL-PRF-39012,
connector
(millimeters)
1/
M39012/68-
appendix B
Maximum
M17/
CATEGORY C FIELD REPLACEABLE (MIL-C-22520/5 BASIC CRIMP TOOL) 5/
Cable group I ~
0016 3/
M39012/67-0016
93-RG178 * @
M39012/69-0016
169-00001 %
A
1.10 (27.94)
Cable group IIa &
0017 3/
M39012/67-0017
113-RG316 * @
M39012/69-0017
172-00001 %
94-RG179 ^
Cable group I ~
4001 3/
M39012/67-4001
93-RG178 * @
M39012/69-4001
169-00001 %
Cable group IIa &
4002 3/
M39012/67-4002
113-RG316 * @
M39012/69-4002
172-00001 %
94-RG179 ^
1/ Mating connector Part or Identifying Number (PIN) is for reference only. All mating connectors
may not be listed.
2/ Dimensions are in inches. Metric equivalents are given for information only.
3/ These connectors have captivated center contacts.
4/ Connector bodies shall be gold plated in accordance with ASTM B488, type II, code C, class 1.27.
5/ Category C connectors are assembled by means of the applicable crimping tool in accordance
with MIL-DTL-22520 to the specified cable stripped as specified on figure 2.
# The latest version of each cable shall be applicable.
* Cable to be used when performing tests requiring cable except as in notes @ and ^.
@ Cable to be used for the +200°C thermal shock tests.
^ These are not 50 ohm cables, therefore, when attached to the specified connectors, VSWR,
RF leakage and insertion loss are not applicable.
~ M22520/5-33 closure B or M22520/5-03 closure B.
& M22520/5-35 closure B or M22520/503 closure A.
% Caution is directed to the applicable of this cable above 400 MHz. Attenuation is tested only at
400 MHz. SRL and power handling capabilities are not stipulated herein.
3
