MIL-PRF-39012/68D
RF high potential withstanding voltage:
Voltage and frequency: Tested at a frequency from 5 to 7.5 MHz.
Leakage current: Not applicable.
Cable group
Volts, rms min.
I
500
II, IIa
700
Cable retention force: The cable retention force shall be as specified in table III.
TABLE III. Cable retention force. 1/ 2/
Cable dielectric
Pounds, min. (N)
Outer diameter
Non-crimp
Crimp
Single braid
Single braid
Center contact
Center contact
Captive
Captive
Inches, max. (mm)
.036 (0.91)
13 (57.83)
13 (57.83)
.066 (1.68)
25 (111.20)
25 (111.20)
1/ Dimensions are in inches.
2/ Metric equivalents are given for information only.
Coupling mechanism retention force: Not applicable.
RF leakage: -55 dB minimum, tested at frequency between 2 and 3 GHz..
RF insertion loss: .30 dB maximum tested at 4 GHz.
PIN: M39012/68 (dash number in table I or IV as applicable).
Group qualification: See table V.
Cross reference of PIN: See table VI.
