MIL-PRF-39012/68D
TABLE V. Group qualification and retention testing.
Group
Submission and retention of
Qualifies the following
Qualification of any of the
connectors
following connectors 1/
M39012/
M39012/
I
68-0003
68-0003
70-0003
68-0103 2/
70-0003
70-0103 2/
II
68-0004
68-0004
70-0004
68-0104 2/
70-0004
70-0104 2/
III
68B0008
68B0008
70B0008
68B0013 2/
70B0008
70B0013 2/
IV
68B0009
68B0009
70B0009
68B0010
68B0014 2/
68B0015 2/
70B0009
70B0010
70B0014 2/
70B0015 2/
V
68B0010
68B0010
70B0010
68B0015
70B0010
70B0015 2/
VI
68-0011
68-0011
70-0011
68-0016
70-0011
70-0016 2/
VII
68-0012
68-0012
70-0012
68-0017
70-0012
70-0017 2/
1/ Individual connectors other than listed are self qualifying only.
2/ Corrosion and contact resistance test data must be submitted to DSCC-VQ before qualification
approval may be granted.
NOTES:
1. If a connector manufacturer produces a connector which meets all the requirements for two or more
connector PINs (within the same series), the manufacturer may receive qualification approval for two
or more connector PINs by qualifying the one connector. It is not necessary that such connectors be
in the same group. Each connector, however, must be marked with its own appropriate PIN. For
group qualification, the connectors must be of similar design.
2. For qualification retention, where more than one part is listed in a group in this column, data may be
supplied on any of those parts in order to retain qualification for those parts in the corresponding right-
hand column. The part does not necessarily have to be the part initially qualified.
9
