MIL-PRF-39012/76D
TABLE V. Group qualification and retention testing.
Group
Submission and retention of
Qualifies the following connectors
Qualification of any of the following
connectors 1/
M39012/
M39012/
I
74-0003
74-0003
76-0003
74-0103 2/
76-0003
76-0103 2/
II
74-0004
74-0004
76-0004
74-0104 2/
76-0004
76-0104 2/
III
74B0008
74B0008
76B0008
74B0014 2/
76B0008
76B0014 2/
IV
74B0009
74B0009
76B0009
74B0010
74B0015 2/
74B0016 2/
76B0009
76B0010
76B0015 2/
76B0016 2/
V
74B0010
74B0010
76B0010
74B0016 2/
76B0010
76B0016 2/
VI
74-0011
74-0011
76-0011
74-0017 2/
76-0011
76-0017 2/
VII
74-0012
74-0012
76-0012
74-0018 2/
76-0012
76-0018 2/
VIII
74-0013
74-0013
76-0013
76-0013
1/ Individual connectors other than listed are self qualifying only.
2/ Corrosion and contact resistance test data must be submitted to DSCC-VQ before qualification
approval may be granted.
NOTES:
1. If a connector manufacturer produces a connector which meets all the requirements for two or more
connector PINs (within the same series), the manufacturer may receive qualification approval for two or more
connector PINs by qualifying the one connector. It is not necessary that such connectors be in the same group.
Each connector, however, must be marked with its own appropriate PIN. For group qualification, the connectors
must be of similar design.
2. For qualification retention, where more than one part is listed in a group in this column, data may be
supplied on any of those parts in order to retain qualification for those parts in the corresponding right-hand
column. The part does not necessarily have to be the part initially qualified.
10
