MIL-PRF-39012/76D
TABLE I. Dash numbers, cross-reference, and dimensions Continued.
Dash No.
# Applicable cable
Typical mating
Dimensions
Inches
group from MIL-
Connector
(millimeters)
1/
M39012/76
PRF-39012,
Maximum
2/
appendix B
M17/
CATEGORY C FIELD REPLACEABLE (MIL-C-22520/5 CRIMP TOOL) 5/
Cable group I ~
0017 3/
M39012/73-0017
93-RG178 * @
M39012/75-0017
169-00001 %
Cable group IIa &
A
1.20 (30.48)
0018 3/
M39012/73-0018
113-RG316 * @
M39012/75-0018
172-00001 %
94-RG179 ^
4001 3/
Cable group I ~
M39012/73-4001
93-RG178 * @
M39012/75-4001
169-00001 %
A
1.10 (27.94)
4002 3/
Cable group IIa &
M39012/73-4002
113-RG316 * @
M39012/75-4002
172-00001 %
94-RG179 ^
1/ Mating connector Part or Identifying Number (PIN) is for reference only. All mating connectors
may not be listed.
2/ Dimensions are in inches. Metric equivalents are given for information only.
3/ These connectors have captivated center contacts.
4/ Connector bodies shall be gold plated in accordance with ASTM B488, type II, code C, class 1.27.
5/ Category C connectors are assembled by means of the applicable crimping tool in accordance
with MIL-DTL-22520 to the specified cable stripped as specified on figure 2.
# The latest version of each cable shall be applicable.
* Cable to be used when performing tests requiring cable except as in notes @ and ^.
@ Cable to be used for the +200°C thermal shock tests.
^ These are not 50 ohm cables, therefore, when attached to the specified connectors, VSWR, RF
leakage and insertion loss are not applicable.
~ M22520/5-33 closure B or M22520/5-03 closure B.
& M22520/5-35 closure B or M22520/5-03 closure A.
$ M22520/5-41 closure B or M22520/5-05 closure B or M22520/5-09 closure A.
% Caution is directed to the applicable of this cable above 400 MHz. Attenuation is tested only at
400 MHz. SRL and power handling capabilities are not stipulated herein.
4
