MIL-PRF-39012/76D
Cable retention force: The cable retention force shall be as specified in table III.
TABLE III. Cable retention force. 1/ 2/
Pounds, min. (N)
Cable dielectric
Non-crimp
Crimp
Outer diameter
Single braid
Single braid
Center contact
Center contact
Captive
Captive
Inches, max. (mm)
.036 (0.91)
13 (57.83)
13 (57.83)
.066 (1.68)
25 (111.20)
25 (111.20)
1/ Dimensions are in inches.
2/ Metric equivalents are given for information only.
Coupling mechanism retention force: Not applicable.
RF leakage: -60 dB minimum, tested at frequency between 2 and 3 GHz..
RF insertion loss: .25 dB maximum tested at 4 GHz.
PIN: M39012/76 (dash number from table I or IV as applicable).
Group qualification: See table V.
Cross-reference of PINs: See table VI.
