MIL-DTL-12883/41F
TABLE III. Insertion and withdrawal forces.
M12883/41
Condition
-01 through 04
-16 through 19
-06 through 09
-05, 10, -15 and -20
-11 through 14
Insertion force (max)
15 lbf (66.72 newton)
17.5 lbf (77.84 newton)
Initial
Withdrawal force (min)
1.0 lbf (4.45 newton)
1.1 lbf (4.89 newton)
After 10
Insertion force (max)
15 lbf (66.72 newton)
17.5 lbf (77.84 newton)
insertions and
withdrawals,
and before
Withdrawal force (min)
1.0 lbf (4.45 newton)
1.1 lbf (4.89 newton)
vibration
Insertion force (max)
14 lbf (62.28 newton)
16.25 lbf (72.28 newton)
After vibration
Withdrawal force (min)
.75 lbf (3.34 newton)
.82 lbf (3.65 newton)
Mounting hardware: The mounting hardware shall allow mounting the socket above, or below the
panel or chassis (see figures 2 and 3), and shall allow mounting and securing the relay to the socket
without disturbing the mounted socket or access to the wiring side of the socket. The hardware shall
provide the nominal spacing between socket surface and relay mounting flange, regardless or
mounting configuration, (see figures 2 and 3).
Supplied with relay socket:
4 each .112-40 self locking nuts (.206 max dia x .176 max height).
4 each .112 flat washers (.220 max O.D. x .018 max thick).
2 each .190-32 self locking nuts (.330 max dia x .190 max height).
2 each .190 flat washers (.360 max O.D. x .036 max height).
2 each studs for loose mounting configuration only (see figure 2).
Fixed mounting studs: Studs shall be molded into the mounting flange of the socket and shall be
designated so as to prevent rotation of the stud within the flange (see figure 3).
Contact installation tools shall be in accordance with table IV.
TABLE IV. Contact installation tools.
Part or Identifying Number (PIN)
Tool
Nomenclature
Size 16 contacts
Size 22 contacts
Crimp
M22520/1-01, /7-01
M22520/2-01
Positioner
M22520/1-02, /7-03
M22520/2-06
Unwired
M81969/30-06, /30-05
M81969/30-01
Insertion/removal
Wired
M81969/8-06, /8-08, /14-02 /14-03
M81969/8-04, /14-01
11
