MIL-DTL-12883/41F
Inches
mm
Inches
mm
Inches
mm
Inches
mm
Inches
mm
27.43
1.080
9.02
.355
3.81
.150
1.5
.06
0.040
.0015
27.56
1.085
10.16
.400
4.83
.190
1.98
.078
0.13
.005
28.19
1.110
10.24
.403
5.08
.200
2.3
.09
0.876
.0345
25.91
1.020
12.70
.500
5.59
.220
2.54
.100
0.94
.037
27.56
1.085
13.46
.53
7.04
.277
2.84
.112
1.27
.050
35.71
1.406
14.10
.555
7.62
.300
3.18
.125
13.46
.53
44.20
1.74
15.24
.600
8.51
.335
3.76
.148
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is +005 inch (0.13 mm) for three place decimals and +.01
inch (0.25 mm) for two place decimals.
4. Point of electrical contact engagement, from mating face of socket insulator to the socket contact.
5. Marking shall be characters, which are molded .035 inch (0.89 mm) minimum. Ink marking optional
(see MIL-STD-1285).
6. Keyway is shown for loose stud mounting configuration only (see figure 2 detail A).
7. For mating relay (see table I).
8. Configuration mounting (see figures 2, 3, and table I).
9. Shape is optional.
10. Hole depth shall be:
01 through 10 depth shall be .370 inch (9.40 mm) min.
11 through 20 depth shall be .233 inch (5.92 mm) min.
4
