MIL-DTL-24231/3E(SH)
12
Ø17
CABLE TYPE AND LENGTH AS
8
SPECIFIED IN THE CONTRACT
OR ORDER.
COMPOUND, EPOXY 16
3 MIN
COMPOUND,
11
POLYURETHANE
SOCKET, CONTACT
9
1
(SOFT SOLDER TO COND)
45°
9
32
1
SLEEVE, PLUG
COUPLING,
5
6
M24231/3-010
M24231/3-011
INSERT ASSEMBLY 13 14
KEY MUST BE LOCATED
IN POSITION SHOWN.
SEVEN CONDUCTOR
NINE CONDUCTOR
1
2
PLUG ASSEMBLY
PLUG ASSEMBLY
M24231/3-001
M24231/3-002
SYMBOL NO. 713.1
SYMBOL NO. 713.7
FIGURE 1. Connector, plug, molded, seven-, and nine-conductor (straight).
