MIL-DTL-24231-3 Connector, Plug, Type I, Molder, Seven- And Nine-Conductor \(Straight And 90 Degrees\)

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9


MIL-DTL-24231/3E(SH)
M24231/3-001
OR
M24231/3-002
OR
M24231/3-003
OR
M24231/3-004
GASKET O-RING,
9
SAE-AS28775-220
8
SEALING PLUG
FIGURE 6. Sealing plug assembly ­ M24231/3-020.
15
6
