MIL-DTL-24231/3E(SH)
TABLE I. Parts list Continued.
NOTES:
1/
Item numbers are the same as encircled numbers shown on figures.
2/
See applicable figure or table listed in remarks column for part numbers and dimensions.
3/
Quantity is for one complete assembly of each size.
4/
When plugs are purchased as a kit, the inserts are not molded in accordance with MIL-DTL-24231/29. The
socket contacts and sleeving are individually provided.
GRE plug sleeves may be obtained from D.G. O Brien, Inc., Sea Con/Phoenix, Inc., or equal.
5/
6/
May be Ni-Al-BRZ in accordance with ASTM B150/B150M at the option of the manufacturer.
7/
Molding compound to be procured in accordance with S9320-AM-PRO-020.
8/
For cable type, see table for cross indexing of mating plugs, receptacles, adapters, and single and multiple
cable connectors of MIL-DTL-24231.
9/
To be supplied when specified (see acquisition requirements in MIL-DTL-24231).
10/
Hysol base EE4183 or RE2039, hardener HD-3561, Hysol Division, Dexter Corporation, Olean, NY, CAGE
04347, or equal.
