MIL-DTL-24231/3E(SH)
COMPOUND, EPOXY 16
33 MAX
4
SR 15
16
INSERT ASSEMBLY 13 14
17
8
TERMINATE
SHIELD HERE.
SEE REQT 2.
PLUG SLEEVE
M24231/3-010 MOD.
SEE REQT 3.
3 MIN
1
4
5
MOLD PART NO.'S
1
IN 8 HIGH LTRS
COMPOUND, POLYURETHANE 11
CABLE TYPE AND LENGTH AS SPECIFIED.
KEY MUST BE LOCATED
IN POSITION SHOWN.
1
6
1
2
3
7
9
4
8
5
2
6
5
7
3
4
SEVEN CONDUCTOR
NINE CONDUCTOR
90° PLUG ASSEMBLY
90° PLUG ASSEMBLY
M24231/3-003
M24231/3-004
3
4
SAME AS M24231/3-001
SAME AS M24231/3-002
EXCEPT AS SHOWN
EXCEPT AS SHOWN
FIGURE 7. Connector, plug, molded, seven- and nine-conductor (90-degree).
TABLE I. Parts list.
7
