MIL-DTL-24231/30A(SH)
TABLE I. Parts list.
Quantity for
Item
M24231/30- 3/
2/
no.
Description
Material/specification
Remarks
1/
001
002
4/
1
Plug assembly, 3-conductor
1
463-6548331
See figure 1.
4/
2
Plug assembly, 4-conductor
1
See figure 1.
5/
3
Glass-reinforced epoxy
1
1
463-6548326
See figure 2.
(GRE) plug body assembly
4
Cable
As required
See ordering data.
See figure 1.
5
Guidekey sleeve
1
1
463-6548329
See figure 6.
Stainless steel, AISI Type 316L
6
Coupling
1
1
463-6548334
See figure 3.
Ni-Al-BRZ, ASTM B150/B150M
7
Electrical socket contact
3
4
463-6546692
See figure 5 and
assembly
Copper alloy 360,
continuation of figure 5.
ASTM B121/B121M,
ASTM B36/B36M,
ASTM B16/B16M, and
ASTM B124/B124M finish per
ASTM B488, Code C, Type 2,
Class 1.3, Ni under-coat per
SAE-AMS-QQ-N-290 6/
8
Cap, protective
1
1
Neoprene rubber compound
Nonpressure-proof, see
figure 4, durometer 855
ASTM D2000,
2B3725B14C12EA14(7%) with
when molded, shrinkage
1.2 1.3% max.
10% teflon powder
9
Gasket, O-ring
SAE-AS28775-215
Shown for information
only. See figure 8.
8/
10
Compound, polyurethane
As required
See figure 1.
7/
11
Compound, epoxy
As required
Cast epoxy resin compound
Base EE4183 or RE2039,
hardener HD-3561;
see figure 1.
12
Gasket, O-ring
3
4
SAE-AS29513-003
Lubricate with silicone
compound, SAE-AS8660,
see figure 7.
13
Secondary o-ring sealing
1
1
See item 12.
See figure 7. Sealing
system
system consists of
appropriate number of
item 12.
3/
14
Sealing plug assembly
1
1
See items 1 and 2, and M24231/1, Pressure-proof, see
item 8.
figure 8, and figure 2 of
MIL-DTL-24231/1E.
3/
15
Sealing plug
1
1
Ni-Cu, Class A, QQ-N-281; see
Pressure-proof, see
M24231/1, figure 2, item 8
11
