MIL-DTL-24231/30A(SH)
SEE DETAIL "A"
1.688-12UN-2A
A
4 X 0.250
4 X SR 0.120
Ø1.281
Ø1.810
0.060R
0.350
A
0.147
0.730
1.500
0.020R
0.190
0.085
0.250
Ø0.940
0.060R
Ø1.560
0.690
Ø1.220
Ø1.332
SECTION A-A
DETAIL "A"
NOTE: DIMENSIONS SHOWN ARE FOR MOLD INFORMATION ONLY. ACTUAL PART
DIMENSIONS MAY VARY BASED ON SHRINKAGE (SEE TABLE I).
FIGURE 4. Protective cap M24231/30-012.
