MIL-DTL-24231/30A(SH)
TABLE I. Parts list Continued.
Quantity for
Item
M24231/30- 3/
2/
no.
Description
Material/specification
Remarks
1/
001
002
16
Adhesive primer,
As required
463-6548333 adhesive primer,
See figure 1.
rubber-to-plastic
rubber-to-metal, two-part,
Type I, for polyurethane
molding 9/;
or rubber-to-metal primer and
adhesive for neoprene 10/
17
Adhesive primer,
As required
463-6548332 adhesive primer,
See figure 1.
rubber-to-rubber
rubber-to-rubber, one-part,
Type I, for polyurethane 11/;
or adhesive one-part for
neoprene 12/
NOTES:
1/
Item numbers are the same as encircled numbers shown on figures.
2/
See applicable figure or table listed in remarks column for part numbers and dimensions.
3/
Quantity is for one complete assembly of each size.
4/
To be supplied molded to cable unless otherwise specified (see acquisition requirements in MIL-DTL-24231).
5/
Glass reinforced epoxy (GRE), Fiberite Corp., Winona, MA, part no. E-2748, CAGE 07314, or equal.
6/
Electrical socket contact, Hugin Industries, Los Altos, CA, part no. 04008, CAGE 1P172, or equal.
7/
Hysol base EE4183 or RE2039, hardener HD-3561, Hysol Division, Dexter Corporation, Olean, NY,
CAGE 04347, or equal.
8/
Molding compound to be procured in accordance with S9320-AM-PRO-020.
9/
PR-420, Products Research and Chem. Corp., Glendale, CA, or equal.
10/
Chemlok 205 primer, Chemlok 234B adhesive, Hughson Chem Corp., Div. of Lord Corp., Erie PA, or equal.
11/
PR-1523M, Products Research and Chem. Corp., Glendale, CA, or equal.
12/
Chemlok 234B adhesive, or equal.
CHANGES FROM PREVIOUS ISSUE. Marginal notations are not used in this revision to identify changes
with respect to the previous issue due to the extent of the changes.
Preparing activity:
Navy SH
(Project 5935-2011-079)
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above using the
ASSIST Online database at https://assist.dla.mil.
12
