MIL-DTL-24231/30A(SH)
+0.0002
Ø0.1033 -0.0002
-A-
+0.001
Ø0.083 -0.001
Ø0.125
Ø0.002 M A M
Ø0.002 M A M
MEDIUM DIAMOND KNURL
Ø0.070
0.465
0.040R
Ø0.002 M A M
0.335
0.060
45°
+0.0005
Ø0.750
Ø0.093-0.0005
0.750
0.500
0.250
Ø0.002 M A M
SEE VIEW "A"
Ø0.002 M A M
1.804
0.485
1.798
FOR ALTERNATE
CONSTRUCTION
+0.003
2.286 -0.003
SOCKET CONTACT
+0.0002
Ø0.0733 -0.0002
+0.0005
Ø0.1040 -0.0005
Ø0.002 M B M
-B-
Ø0.093
45°
0.495
Ø0.125
+0.002
Ø0.002 M B M
0.535 -0.002
SLEEVE
CRIMP SLEEVE AT LOCATION SHOWN AROUND CIRCUMFERENCE
OF SOCKET AT 4 LOCATIONS 90° APART 0.006+0.003 INCH DEEP
0.003
-
WITH 0.092+0.005 DIAMETER CRIMP DIE.
0.005
-
+0.010
0.435 -0.010
SEE VIEW "B" FOR
ASSEMBLY
ALTERNATE ASSEMBLY
FIGURE 5. Socket contact assembly M24231/30-030.
7
6
