MIL-DTL-24231-5 Connector, Single Cable, Type Iii, Three-, Four-, Or Five-Conductor

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16


MIL-DTL-24231/5E(SH)
0.238 (TYP)
0.228
0.140 (TYP)
0.130
7
Ø64, 4 HOLES.
1.114
Ø1.104
3
16
1
X 45° BEVEL, BOTH SIDES.
32
63
FIGURE 9. Plate, retainer ­ M24231/5-061.
29
11
