MIL-DTL-24231/5E(SH)
4 HOLES, SIZE AND LOCATION
SAME AS RETAINER PLATE.
BEVELS NOT REQUIRED.
1.114
Ø 1.014
3
4
FIGURE 10. Packing M24231/5-063.
35
1.255
SAME AS M24231/5-061
Ø
31
1.245
EXCEPT AS SHOWN.
PLATE, RETAINER
3
32
M24231/5-062
0.067R
0.057
3
16
PIN, POSITIONING, M24231/5-054 (FORCE FIT) 26
FIGURE 11. Assembly, retainer plate M24231/5-060.
11
12
