MIL-DTL-24231/5E(SH)
0.238 (TYP)
0.228
0.140 (TYP)
0.130
Ø674, 5 HOLES.
1.114
Ø1.104
3
16
1
X 45° BEVEL, BOTH SIDES.
32
SEE REQUIREMENT 5.
63
FIGURE 13. Plate, retainer ­ M24231/5-064.
30
14
