MIL-DTL-24231/5E(SH)
5 HOLES, SIZE AND LOCATION
SAME AS RETAINER PLATE.
BEVELS NOT REQUIRED.
1.114
Ø1.014
3
4
FIGURE 14. Packing M24231/5-085.
36
32
1.255
PLATE, RETAINER
Ø1.245
M24231/5-065
3
SAME AS M24231/5-064
32
0.067R
EXCEPT AS SHOWN.
0.057
3
16
PIN, POSITIONING, M24231/5-054 (FORCE FIT) 26
FIGURE 15. Assembly, retainer plate M24231/5-066.
