MIL-DTL-24231/5E(SH)
X
0.051
0.041
3
8
1
8
PIN, M24231/5-071
DRILL 3 DEEP (MAX).
8
DO NOT PENETRATE THRU WALL.
USE NO. 42 DRILL.
CONNECTOR
"X"
DEGREES
BODY
1
M24231/5-070
212
1
M24231/6-010
212
M24231/7-040
27
M24231/8-020
27
M24231/9-030
27
NOTE: INSTALL PIN WITH LOCKING AND
RETAINING COMPOUND IN ACCORDANCE WITH
M24231/9-040
27
GRADE "A" OF MIL-S-22473.
35
M24231/10-040
40
M24231/19-010
25
FIGURE 3. Alternate method for installation of guide pin (see requirement 4).
6
