MIL-DTL-24308G
3.5.3 Contact insertion and removal forces. The axial forces required to insert and remove removable contacts
TABLE I. Contact insertion and removal forces (pounds maximum).
Contact size
20
22D
Insertion
4
4
Removal
4
4
3.5.4 Mating and unmating force. The force for mating and unmating of counterpart connectors shall meet the
requirements in table II. The connectors used in this test shall have the complete complement of contacts. Testing
shall be as specified in 4.5.6.
TABLE II. Mating and unmating forces (pounds).
Shell
Unmating
Mating
size
Minimum
Maximum
Maximum
Class
Class
Class
G, D, M,
H, K
G, D, M,
H, K
G, D, M, N
H, K
N
N
1
0.75
1.50
6.0
7.00
10.0
7.25
2
1.00
2.00
10.0
13.00
17.0
13.00
3
1.75
3.25
17.0
21.25
28.0
21.25
4
2.50
4.50
24.0
31.25
39.0
31.25
5
3.25
5.50
30.0
42.25
49.0
42.25
6
4.50
----
39.0
-----
65.0
-----
3.5.5 Contact retention. Contacts for classes G, D, M, and N connectors shall be retained in their inserts by a 9-
pound (minimum) force. The axial displacement of contacts shall not exceed .012 inch (0.30 mm) while under load
(see 4.5.7).
3.5.6 Dielectric withstanding voltage. Unmated connectors shall show no evidence of breakdown or flashover
when subjected to the test voltages and altitudes specified in tables III and IV. Corona shall not be considered as
breakdown. Testing shall be as specified in 4.5.8.
TABLE III. Type I and II test voltage (Volts rms, 60 Hz). 1/
Humidity conditioned
All other
Altitude
(see 4.5.15)
Conditions
Classes
Classes
Classes
Classes
G, D, M, N
H, K
G, D, M, N
H, K
Sea level
600
400
1,000
750
70,000 feet
---
---
325
175
1/ These are not working voltages.
TABLE IV. Type III test voltage (Volts rms, 60 Hz). 1/
All other
Humidity
conditions
Altitude
conditioned
(see 4.5.15)
Class G
Sea level
500
500
70,000 feet
---
200
1/ These are not working voltages.
10
