MIL-DTL-24308G
3.5.7 Cable retention (flat cable only). When connectors are tested as specified in 4.5.9, they shall withstand the
minimum applied force without mechanical damage.
3.5.8 Insulation resistance at ambient temperature. The insulation resistance of unmated connectors shall conform
to the applicable requirements in table V when tested as specified in 4.5.10.
TABLE V. Insulation resistance (megohms minimum).
Humidity conditioned (see 4.5.15)
After step 6 of test
After 24 hours of conditioning
All other
procedure EIA-364-31
test procedure EIA-364-31
conditions
Megohms (min)
Megohms (min)
Megohms (min)
1
1,000
5,000
3.5.9 Contact resistance. Contact resistance for mated pairs of pin and socket contacts shall be as specified in
table VI when tested as specified in 4.5.11.
TABLE VI. Contact resistance (millivolts maximum).
Contacts
Classes
Test
AWG
Contact
current
wire
size or
(amperes)
size
type
G, D, M, N
H, K
After
All others
After
All others
salt spray conditions
salt spray
conditions
24
3.0
55
45
---
---
20
20
7.5
65
55
---
---
24
2.0
---
---
ind 165
ind 165
20
5.0
---
---
avg 90
avg 70
IDC
28
1.0
75
65
---
---
PWB
24
3.0
55
45
---
---
3.5.10 Contact engagement and separation forces. Socket contacts shall conform to the forces specified in table
TABLE VII. Contact engagement and separation forces (ounces).
Initial
Minimum separation
Maximum average
Maximum individual
Solder
force using
engagement force
engagement force
contact
minimum diameter
using maximum
using maximum
size
test pin
diameter test pin
diameter test pin
22D
12.0
9.5
0.7
20
18.0
12.0
0.7
IDC
18.0
12.0
0.7
After conditioning
22D
14
11.4
0.6
20
22
14
0.6
IDC
22
14
0.6
11
