MIL-DTL-24308G
TABLE XI. Qualification inspection Continued.
1/
Connector class:
1.
Classes D and G
-Removable contact connectors.
2.
Classes D and G
-Nonremovable contact connectors.
3.
Classes M and N
-Removable contact connectors.
4.
Classes M and N
-Nonremovable contact connectors.
5.
Classes H and K
-Nonremovable contact connectors.
2/
Not applicable for periodic inspection.
3/
Not applicable for non-removable contacts.
4/
DC Connectors shall meet the test requirements specified for classes G and D nonremovable contact
connectors.
5/
See 4.5.1.1 (nonmetallic materials of two connector assemblies).
6/
Not applicable for crimp, wrappost, and IDC contacts.
7/
Not applicable for hermetic connectors.
4.4 Conformance inspection.
4.4.1 Inspection of product for delivery. Inspection of product for delivery shall consist of group A inspection.
4.4.1.1 Inspection lot. An inspection lot shall consist of all connectors or removable crimp contacts, as applicable,
covered by one specification sheet, produced under essentially the same conditions, and offered for inspection at one
time.
4.4.1.2 Group A inspection. Group A inspection shall consist of the inspections specified in Table XII, in the order
shown.
4.4.1.2.1 Sampling plan (group A). Table XII tests shall be performed on a production lot basis. Samples shall be
selected as specified in table XIII. If one or more defects are found, the lot shall be screened for that particular defect
and the defective parts removed. A new sample of parts shall be selected as specified in table XIII and all group A
tests again performed. If one or more defects are found in the second sample, the lot shall be rejected and shall not
be supplied to this specification.
TABLE XII. Group A inspection.
Test method
Inspection
Requirement
paragraph
paragraph
Visual and mechanical inspection
Contact engagement and separation forces
(nonremovable contacts)
Insulation resistance at ambient
temperature
Dielectric withstanding voltage
(sea level)
16
