MIL-DTL-27434B
TABLE VI. Inspection level (group B).
Lot size
Sample size
100%
1
to
4
5
5
to
90
11
91
to
150
13
151
to
280
16
281
to
500
19
501
to
1,200
23
1,201
to
3,200
29
3,201
to
10,000
35
10,001
to
35,000
40
35,001
or more
4.3.1.3.2 Disposition of sample units. Sample units which have passed the group B inspection, shall
be delivered on the contract or order, if the lot is accepted.
4.3.1.3.3 Action in case of lot rejection. When an inspection lot is rejected on group B inspection, the
supplier shall immediately investigate the cause of failure and take corrective action to assure that
subsequent lots do not contain the same defect or defects.
4.3.1.4 Group C inspection. Group C inspection shall consist of the examinations and test specified in
table VII.
4.3.1.4.1 Sampling plan.
4.3.1.4.1.1 Subgroup 1 (unassembled connector adapters). Six sample units of each type connector
adapter shall be selected from initial production. Every 30 days thereafter, sample units shall be selected
from subsequent production in accordance with table VIII.
TABLE VII. Group C inspection.
Examination or test
Requirement
Method
paragraph
paragraph
Subgroup 1 (unassembled connector adapters)
Detail requirements:
4.4.1
3.1
Physical dimensions 1/
Subgroup 2 (assembled connector adapters)
4.4.6
3.6
Vibration
4.4.7
3.7
Shock
4.4.5
3.5
Salt spray (corrosion)
1/ Only those dimensions related to piece parts shall be checked.
4.3.1.4.1.1.1 Physical dimensions. To facilitate inspection of the physical dimensions, the
unassembled sample units shall be divided into groups of identical piece parts. Inspection of the physical
dimensions shall then be performed on a group-by-group basis.
9
