MIL-DTL-28748 Connector, Plug And Receptacle, Rectangular, Rack And Panel Solder Type And Crimp Type Contacts General Specification ForThis specification covers rectangular, rack and panel, electrical connectors, with nonremovable solder type contacts, and removable crimp type contacts, intended for use in electronic and electrical equipment \(see 6.1\).

Pages 1 - - 6 - 7 - 8|||9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22 - 23 - 24|||


MIL-DTL-28748D
B
.50
MAX
.75
TEN ELECTRICAL CONTACTS
(19.1)
(MATED PINS AND SOCKETS)
PLACED AS SHOWN
PLASTIC MOUNTING
BASE
.50
(12.7)
CONTACT
3.50
(88.9)
LEAD SOLDERED TO WASHER
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Metric equivalents are in parenthesis.
FIGURE 4. Test fixture for salt spray test.
15
