MIL-DTL-3607C
TABLE I. First article inspection.
Inspection
Requirement
Test
Number of units
tables
paragraph
to be tested
Inspection covered by
4.4
Inspection to be performed on all
subsidiary documents
units
Group A inspection
See table II
Inspection to be performed on all
units
Group B inspection
See table III
Inspection to be performed on all
units
Group C inspection
Subgroup 1
See table IV
Inspection to be performed as
specified in test paragraphs
Subgroup 2
See table IV
Inspection to be performed as
specified in test paragraphs
4.3 Inspection covered by subsidiary documents. The following shall be inspected under the applicable
subsidiary documents as part of the inspection required by this specification and the inspection
requirement specified in the contract.
Item
Requirement
paragraph
Finish
3.6
Marking
3.7
4.4 Conformance inspection.
4.4.1 Inspection of product for delivery. Inspection of product for delivery shall consist of groups A, B
and C inspection.
4.4.1.1 Inspection lot. An inspection lot shall consist of all connectors of the same PIN produced under
essentially the same conditions, and offered for inspection at one time.
4.4.1.2 Group A inspection. Group A inspection shall consist of the inspections specified in table II in the
order shown.
4.4.1.2.1 Sampling plan (Group A). Table II tests shall be performed on a production lot basis. Samples
shall be selected in table II-1. If one or more defects are found, the lot shall be screened for that
particular defect and defects removed. A new sample of parts shall be selected in table II-1 and all group
A tests again performed. If one or more defects are found in the second sample, the lot shall be rejected
and shall not be supplied to this specification.
4.4.1.2.2 Visual inspection (Group A inspection). Each connector shall be visually examined for
completeness, workmanship, and identification requirements. Attention shall be given to those
assemblies that require a gasket to determine the condition of the gasket. Gaskets missing, twisted,
buckled, kinked, or damaged in any way shall be cause for rejection.
6
