MIL-DTL-3607C
TABLE II. Group A inspection.
Requirement
Inspection
Inspection
paragraph
paragraph
Visual and mechanical
4.5.1
Marking
3.7
4.5.1
Workmanship1/
3.8
4.5.1
Gage tests for contacts(assembled connectors):
Center contacts (female)
3.3.3.1
4.5.1.2.1
Outer contacts
3.3.3.2
4.5.1.2.2
Dielectric withstanding voltage
3.4
4.5.2
1/ Assembly, fit of parts and playing coverage.
TABLE II-1. Sample and lot size.
Lot size
Sample size
1
to
8
5
9
to
15
5
5
16
to
25
5
26
to
50
5
51
to
90
11
91
to
150
13
151
to
280
16
281
to
500
19
501
to
1,200
23
1,201
to
3,200
29
3,201
to
10,000
35
10,001
to
35,000
40
35,001
to
150,000
40
150,001
to
500,000
40
500,001
to
over
4.4.1.3 Group B inspection. Group B inspection shall consist of the inspections specified in table III in
the order shown, and shall be made on sample units which have been subjected to and passed the group
A inspection. Connectors having identical piece parts may be combined for lot purposes and shall be in
proportion to the quantity of each PIN numbered connector produced.
4.4.1.3.1 Group B sampling plan. A sample of parts shall be randomly selected in table III-1. If one or
more defects are found, the lot shall be screened for that particular defect and defects removed. After
screening and removal of defects, a new sample of parts shall be randomly selected and subjected to all
tests in table III-1. If one or more defects are found in the second sample, the lot shall be rejected and
shall not be supplied to this specification.
4.4.1.3.2 Disposition of sample units. Sample units which have passed all the group B inspection may
be delivered on the contract or purchase order if the lot is accepted. Any connector deformed or
otherwise damaged during testing shall not be delivered on the contract or order.
7
