MIL-DTL-38999/22H
REQUIREMENTS:
Dimensions and configurations: See figures 1 thru 4. Interface dimensions shall conform to
MIL-DTL-38999, except as noted.
This connector mates with MIL-DTL-38999/26, MIL-DTL-38999/29, MIL-DTL-38999/30, and
MIL-DTL-38999/31.
Air leakage: Testing shall be in accordance with EIA-364-02, except the minimum period of
measurement shall be 10 seconds. The air leakage rate shall be no greater than 1 atmospheric cubic
-3
3
inch per hour (4.55 X 10 cm /s) Stowage receptacles shall be mated to connectors having either
contacts or inserts removed so that a pressure of 10 lbft/in2 (.703 Kg/cm2 ) can be applied against the
insides of the stowage receptacles.
Qualification (all classes). Qualification shall be in accordance with MIL-DTL-38999, conducted on
two samples of each shell size, except only the following sequence of tests shall be required:
Examination of product
Coupling torque
Dynamic salt spray (corrosion)
Air leakage (see requirement)
Visual and mechanical
Qualification (classes J and M only): Qualification shall be in accordance with MIL-DTL-38999,
except that in addition to the test sequence specified for all classes above, the following tests shall be
required:
Temperature cycling
Hydrolytic stability
Group A sampling inspection. Sampling for group A inspection shall be as specified in table I.
TABLE I. Group A sampling plan.
Lot size
Sampling size
1 to 13
100 percent
14 to 150
13 units
151 to 280
20 units
281 to 500
29 units
501 to 1,200
34 units
1,201 to 3,200
42 units
3,201 and up
54 units
8
