MIL-DTL-83517/11A
Inches
mm
.001
.03
.010
.25
.015
.38
.0355
.90
.0370
.94
.050
1.27
.100
2.54
.517
13.13
.728
18.49
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. All undimensioned pictorial configurations are for reference purposes only.
4. Number two screws are suggested for mounting.
FIGURE 7. Transition pin.
Inches
mm
.001
.03
.002
.05
"A" dim.
.051
1.30
.625 ±.002
.070
1.78
.132
3.35
NOTES:
.162
4.11
.625
15.88
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. All undimensioned pictorial configurations are for reference purposes only.
4. Number two screws are suggested for mounting.
FIGURE 8. Rear dielectric.
7
