MIL-PRF-39012/38J
TABLE III. Category B non-field replaceable (special tools may be required). 1/
NOT FOR ARMY, NAVY, OR AIR FORCE USE. FOR OEM USE ONLY
PIN 2/ 3/
Applicable cable 4/
Dimensions
Inches (millimeters) 7/
M39012/38B
M17
Maximum
0015
75-RG214 5/
RG-225/U 6/
A
1.843 (46.81)
0016
073-RG212
112-RG304
0017
92-RG115 6/
1/
For maintenance replacements for category B, see table V.
2/
For cross-reference of dash number to superseded PIN or type designation, see table IV.
3/
These connectors have captivated center contacts.
4/
The latest version of each cable shall be applicable.
5/
Cable to be used when performing tests requiring cable except as in 6/.
6/
Cable to be used for the +200°C temperature cycling tests.
7/
Dimensions are in inches. Metric equivalents are given for information only.
TABLE IV. Supersession data. 1/
Preferred PIN
Superseded PIN or type
M39012/38
designation
M39012/38
-0010
-0001
-0011
-0002
-0012
-0009
B0015
-0015
B0016
-0016
B0017
-0017
1/ The superseded PIN or type designation is for cross-reference only.
Where a superseded PIN or type designation is not given, none was assigned or will be
assigned. The PIN M39012/38-XXXX shall be used, where XXXX is the correct dash
number, in all cases for marking and identifying the connector.
TABLE V. Maintenance replacements for category B.
Category B number 1/
Category C dash
Category A dash
Category D dash
number
number
number
B0015
0007
0010
0501
B0016
0008
0011
---------
B0017
0018
0013
---------
1/ Category B connectors are for original installation only. They will not be stocked or procured by the
government.
12
