MIL-PRF-39012/38J
TABLE I. Dash numbers, cross-reference, and dimensions Continued.
Dash No. 1/
Applicable cable 2/
Dimensions
Inches *
M17/
(millimeters)
Maximum
CATEGORY C FIELD REPLACEABLE (MIL-C-22520/5 CRIMP TOOL)
SEE NOTE NEXT TO APPLICABLE CABLE GROUP FOR CRIMP DIE 3/ 7/
Cable group VIII 8/
X008
2-RG6 4/
180-00001 4/
112-RG304 5/
Cable group XA 9/
X006
65-RG165 5/ 6/
A
1.843 (46.81)
Cable group XB 9/
X007
127-RG393 5/
86-00001 6/
Cable group XC 9/
X013
62-RG144 4/ 5/ 6/
Cable group IX 9/
X018
92-RG115 5/ 6/
CATEGORY D FIELD REPLACEABLE DEFINED PIECE PARTS 3/ 7/ 10/ 11/
Cable group XB
X501
127-RG393 5/
86-00001 6/
Cable group XA
A
1.859 (47.23)
X502
65-RG165 5/
Cable group VIB
X503
128-RG400 5/
60-RG142 6/
