MIL-PRF-39012/38J
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.001
0.03
.043
1.09
.250
6.35
.500
12.70
.002
0.05
.098
2.49
.292
7.42
.600
15.24
.003
0.08
.104
2.64
.375
9.52
10.01
.005
0.13
.120
3.05
.394
11.13
.015
0.38
.156
3.96
.438
12.50
.031
0.79
.220
5.59
.492
.036
0.91
.234
5.94
Dash No.
Contact
A
Basic
Crimp die
Crimp
Color band
Color band
No. 1/
(inches)
crimp tool
or
tensile
2/
positioner
minimum
X501
38-10
.098 ±.002
60 pounds
Red
X502
M22520/1-
M22520/1-
(266.90 N)
White
01
14
X503
38-11
.043 +.001
20 pounds
Blue
-.002
(88.96 N)
1/ Contact numbers are for identification purposes only.
2/ Class 2 tool may be used by OEM (see MIL-DTL-22520).
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Contact material shall be beryllium copper within one year from the date of this specification.
Phosphor bronze contacts are acceptable for government use until stock is purged.
4. Crimp tensile test shall be in accordance with SAE-AS39029.
5. Maximum break of .003 inch (0.08 mm).
6. Copyright notice: All information disclosed in this specification sheet which is or may be copyrighted
is reproduced herein with the express permission of the copyright owner.
7. Color bands shall be positioned such that no coloring material enters the inspection hole.
FIGURE 3. Contact and ferrule dimensions for category D only.
