MIL-PRF-39012/39H
Dash no
Contact no
A
Basic crimp
Crimp die
Crimp
Color
Color
band
1/
(inches)
tool 2/
or
tensile
Band
positioner
minimum
O
0501
39-10
.098 ± .002
M22520/1-01
M22520/1-13
60 pounds
Red
Orange
0502
0503
39-11
.043
20 pounds
Blue
+.001
-.002
1/ Contacts numbers are for identification only.
2/ Class 2 tool may be used by OEM (see MIL-DTL-22520).
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Crimp tensile test shall be in accordance with SAE-AS39029.
4. Maximum break of .003 inch (0.08 mm).
5. Copyright notice: All information disclosed in these specification sheet which is or may be copyrighted
is reproduced herein with the express permission of the copyright owner.
6. Form socket to mate with 063/066 diameter pin.
7. Color bands shall be positioned such that no coloring material enters the inspection hole.
Dash number
Ferrule
A
B
C ± .015
Basic crimp
Crimp die or
number 1/
tool 2/
positioner
M22520/5-
0501
39-50
.492 ± .003
.438 ± .003
.600
25
M22520/5-01
Closure A
0502
39-51
.492 ± .003
.418 ± .003
.600
or 61
0503
39-52
.250 ± .003
.220 ± .003
.500
5, 11, 57
Closure A
or 19
Closure B
1/ Ferrule numbers are for identification only.
2/ Class 2 tools may be used by OEM (see MIL-DTL-22520).
FIGURE 2. Contact and ferrule dimensions for category D only Continued.
5
