MIL-PRF-39012/39H
Leakage (pressurized connectors) Not applicable.
Insulation resistance: Method 302 of MIL-STD-202, test condition B. 5,000 megohms minimum.
Center contact retention: (Applicable to captivated-center-contact connectors only) 15 pounds
minimum axial force for all cables except RG400 and RG142, 6 pounds minimum for RG400 and
RG142.
Corrosion (salt spray): Method 101 of MIL-STD-202, test condition B.
Voltage standing wave ratio (VSWR) From 500 to 11,000 MHz, or approximately 80 percent of upper
cutoff frequency of the cable, whoever is lower.
From 500 to 9,000 MHz 1.35 maximum
From 9,000 to 11,000 MHz 1.50 maximum
Swept frequency VSWR test setup:
Item 6: VSWR shall be less than 1.015 + .005 F (F in GHz).
Item 16: VSWR shall be less than 1.015 + .005 F (f in GHz).
Second step of VSWR checkout procedure VSWR shall be less than 1.045 + .019 F (F in GHz)
Group B inspection VSWR shall be less than 1.10 + .01 F (F in GHz)
Qualification and group C inspection VSWR shall not exceed 1.15.
Connector durability: 500 cycles minimum at 12 cycles/minute maximum. The connector shall meet the
mating characteristics and force to engage and disengage requirements.
Contact resistance: In milliohms maximum.
Initial
After environment
Center contact
2.0
2.5
Outer contact
.15
Not applicable
Braid to body
.05
Not applicable
Dielectric withstanding voltage. Method 301 of MIL-STD-202. 3,000 volts rms minimum at sea level for
connectors using other than RG400 and RG142; 1,500 volts rms minimum for connectors using RG400
and RG142.
Vibration, high frequency. Method 204 of MIL-STD-202, test condition B.
Shock: Method 213 of MIL-STD-202, test condition I.
Thermal shock: Method 107 of MIL-STD-202, test condition B, except test high temperature shall be
+85°C. High temperature shall be +200°C for connectors using +200°C cables (see table I and III).
Moisture resistance: Method 106 of MIL-STD-202. No measurements at high humidity. Insulation
resistance shall be at least 200 megohms within 5 minutes after removal from humidity.
Corona level:
Voltage: 750 volts rms minimum.
Altitude: 70,000 feet.
RF high potential withstanding voltage:
Voltage and frequency: 2,500 volts rms tested at a frequency from 5 to 7.5 MHz.
Leakage current: Not applicable.
Cable retention force:
Noncrimp assemblies: 75 pounds minimum
7
