MIL-PRF-39012/39H
Crimp assemblies.
50 lbs minimum for cables 155-189 OD
60 lbs minimum for cables 190-.229 OD
75 lbs minimum for cables 230-249 OD
90 lbs minimum for cables 250 OD and larger
Coupling mechanism retention force: 100 pounds minimum.
RF leakage: -90 dB minimum, tested at a frequency between 2 and 3 GHz. This requirement may be
meet by qualifying the straight connector version for the same cable under MIL-PRF-39012/35.
Insertion loss:
.21 dB maximum at 9 GHz.
.07 √ F (GHz) dB max tested at 3 GHz and 6 GHz.
Part or Identifying Number (PIN): M39012/39- (dash number from table I or "B" number from table III).
TABLE II. Group qualification. 1/
Group
Submission and qualification of
Qualifies the following
any of the following connectors 2/
connectors
M39012/39
M39012/39
I
-0101
-0101
-0106
-0107
II
B0002
B0002
B0003
B0008
III
-0004
-0004
-0005
-0009
IV
-0501
-0501
-0502
-0502
-0503
V
-0503
-0503
1/ If a connector manufacturer produces a connector which meets all the requirements for two or more
connector PINs (within the same series), the manufacturer may receive qualification approval for two
or more connector PINs by qualifying the one connector. It is not necessary that such connectors be
in the same group. Each connector, however, must be marked with its own appropriate PIN. For
group qualification, the connectors must be of similar design.
2/ For qualification retention, where more than one part is listed in a group in this column, data may be
supplied on any of those parts in order to retain qualification for those parts in the corresponding
right-hand column. The part does not necessarily have to be the part initially qualified.
