MIL-PRF-39012/39H
TABLE III. CATEGORY B nonfield replaceable (special tools may be required). 1/
NOT FOR ARMY, NAVY, OR AIR FORCE USE. FOR OEM USE ONLY
PIN 2/ 3/
Applicable cable 4/
Dimensions
Inches (millimeters)
M39012/39B
M17/
Maximum
0002
65-RG165 5/
74-RG213
A
2.125 (53.98)
0003
75-RG214 6/
RG-225/U 5/
0008
92-RG115 5/
112-RG304
1/ For maintenance replacements for category B, see table V.
2/ For cross-reference of dash number to superseded PIN or type designation, see table
IV.
3/ These connectors have captivated center contacts.
4/ The latest version of each cable shall be applicable.
5/ Cable to be used for the +200°C temperature cycling tests.
6/ Cable to be used when performing tests requiring cable except as in 5/.
TABLE IV. Supersession data. 1/
Preferred PIN
Superseded PIN
or type designation
M39012/39
M39012/39
-0101
-0001
-0106
-0006
-0107
-0007
B002
-0002
B003
-0003
B008
-0008
1/ The superseded PIN or the type designation is for reference only. Where a
superseded PIN or type designation is not given, none was assigned or will be
assigned. The PIN M39012/39-XXXX shall be used in all cases for marking and
identifying the connector.
TABLE V. Maintenance replacements for category B.
Category B Category C
Category A
Category D
number 1/ dash number dash number dash number
B0002
0004
0101
0502
B0003
0005
0101
0502
B0008
0009
0107
0501
1/ Category B connectors are for original installation only. They will not be stocked or
procured by the Government.
