MIL-PRF-39012/80F
TABLE V. Category B Non-field replaceable (special tools may be required). 1/
NOT FOR ARMY, NAVY, OR AIR FORCE USE. FOR OEM USE ONLY.
Applicable cable 5/
Dimensions, maximum (mm) #
M39012/80B
2/ 3/ 4/
A
B
C
D
3001 6/
M17/133-RG405 *
3101 6/ 7/
3002 6/
M17/130-RG402 *
3102 6/ 7/
.738
.575
.625
.850
(18.74)
(14.60)
(15.88)
(21.59)
3003 8/
3103 7/ 8/
M17/133-RG405 *
4003 8/
4103 7/ 8/
3004 8/
3104 7/ 8/
M17/130-RG402 *
4004 8/
4104 7/ 8/
*
Cable to be used when performing tests requiring cable. All cable PIN's on this
specification sheet shall accommodate this connector.
#
Dimensions are in inches. Metric equivalents are given for information only.
1/
Dimensions E and F shown on figure 1 are not applicable to these connectors.
2/
For logistics purposes, only connectors with safety wire holes will be stocked.
3/
All corrosion resistant steel bodied connectors which are designed to be assembled to the
outer conductor using solder shall be gold plated in accordance with ASTM B488, type II,
code C, class 1.27.
4/
Coupling nuts shall be corrosion-resistant steel with a passivated finish in accordance with
SAE-AMS2700, type 2. (Applies to "-3XXX" series connectors only).
5/
MIL-DTL-17 cables are specified by the basic number. The latest version of each cable shall
be applicable.
6/
In active for new design.
7/
No safety wire holes.
8/
These connectors have captivated center contacts.
