MIL-PRF-39012/80F
ENGINEERING DATA:
Nominal impedance: 50 ohms.
Frequency range: 0 to 12.4 GHz. 0 to 18 GHz for M39012/80-3011, -3012, 3111, 3112, 3211, 3212,
3311, 3312, 4011, 4012, 4111, 4112, 4211, 4311 and -4312.
Voltage rating: The voltage rating shall be as specified in table II.
TABLE II. Voltage rating.
Voltage max. at 70,000 ft.
Cables
Voltage max. (sea level)
V rms
V rms
M17/133-RG405 *
335
85
M17/130-RG402 *
500
125
* These voltages apply to all cable Part or Identifying Numbers (PIN) on these specification sheets
even if not listed.
Temperature rating: -65C to +165C.
Category F: Connectors using semirigid cables with standard stripping dimensions and using standard
military assembly tools. The method of assembly of the connector to the cable shall be solderless.
REQUIREMENTS:
Dimensions and configuration: See figure 1 and MIL-STD-348.
Force to engage and disengage:
Longitudinal force: Not applicable.
Torque: 2 inch-pounds, maximum.
Coupling proof torque: 15 inch-pounds, minimum.
Safety wire hole tearout: 15 pounds, minimum.
Inspection conditions: For each test of threaded coupling connector where the test is performed on
mated pairs, the pairs shall be torqued to 7 to 10 inch-pounds.
Mating characteristics: See MIL-STD-348.
Hermetic seal: Not applicable.
Leakage (pressurized connectors): Not applicable.
Insulation resistance: In accordance with MIL-STD-202, method 302, test condition B, 5,000 megohms
minimum.
5
