MIL-PRF-39012/83G
Inches
mm
Inches
mm
.000
0.00
.250
6.35
.002
0.05
.279
7.09
.003
0.08
.281
7.14
.004
0.10
.312
7.92
.018
.404
0.46
10.26
.055
1.40
.410
10.41
.065
1.65
.460
11.68
.103
2.62
.505
12.83
.125
3.18
21.59
.850
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Dimension .505 inch (10.16 mm) is the largest overall envelope of the connector.
4. Wrench flats are to accommodate standard wrench opening in accordance with FED-STD-H28,
appendix 10.
5. All undimensioned pictorial configurations are for reference purposes only.
6. Dimension A defines the overall length of the connector when assembled to the cable.
7. Series SMA, socket contact interface, in accordance with MIL-STD-348.
8. All threads shall be in accordance with FED-STD-H28.
9. For dimensions A and B see table I.
10. This dimensional change shall be effective for all products delivered after 1 April 1993.
FIGURE 1. General configuration Continued.
