MIL-STD-1130 Connections, Electrical, Solderless WrappedThis standard establishes the requirements to produce mechanically and electrically stable, solderless wrapped, electrical connections made with single, solid, round wire and appropriately designed wrapposts terminals.This standard includes:a. Classes and requirements for solderless wrapped connections. b. Description and requirements for the wire used in making the solderless wrapped connections. c. Description and requirements for the wrappost used in making the solderless wrapped connections.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21

MIL-STD-1130C

c. Insufficient number of wrapper turns. (See 5.3.2 and figure 8.)

FIGURE 8. Insufficient turns.

d. End tail (see 3.4) not conforming to the requirements as specified in 5.3.2. (See figure 9.)

FIGURE 9. End tail.

e. Overlapping wrapper turns within a wrapper level. (See figure 10.)

FIGURE 10. Overwrap.
